Time Series of AVHRR Thermal Infrared Images JAN-FEB 1996

This is a time series of AVHRR thermal infrared (band 4, 10.3-11.3 um) images for the Great Lakes spanning January 31-February 13, 1996. Image brightness is proportional to scene radiance, so bright=higher physical temperature and dark=colder physical temperature. Click on an image for an enlarged version.

This time series shows typical conditions for a well-developed ice season. Clouds obscuring the Lakes' surfaces are common. (These images were selected from a larger time series on the basis of being relatively "cloud free" for Lake Superior.) Open water and leads (particularly shore leads) appear as bright white areas. Ice appears as grey tones, with colder (thicker, generally older) ice being darker grey.

Naming convention, n12.96031.2356: NOAA 1 2, julian day 31 of 1996, Greenwich Mean Time of acquisition 23:56 (18:56 local EST).

31 Jan 18:56 n12.96031.2356

1 Feb 13:34 vis ch.2 n14.96032.1834.ch2

1 Feb 13:34 n14.96032.1834

2 Feb 13:23 n14.96033.1823

2 Feb 13:23 vis ch.2 n14.96033.1823.ch2

3 Feb 03:24 n14.96034.0824

3 Feb. 08:06 n12.96034.1306.

3 Feb 19:30 n12.96035.0030

4 Feb 07:44 n12.96035.1244

5 Feb 03:02 n14.96036.0802

5 Feb 18:47 n12.96036.2347

6 Feb 02:51 n14.96037.0751

6 Feb 08:40 n12.96037.1340

9 Feb 13:48 n14.96040.1848

10 Feb 18:38 n12.96041.2338

11 Feb 08:32 n12.96042.1332

12 Feb 03:16 n14.96036.0816

12 Feb 08:10 n12.96043.1310

12 Feb 19:34 n12.96044.0034

13 Feb 03:16 n14.96044.0816

13 Feb 07:48 n12.96044.1248
